800-1200KW diesel marine engine for ship and boat jinan diesel engine cnpc jichai power 800-1000kw diesel marine engine The Perfect Solution for Your Marine Equipment Requirements

  • 800-1200KW diesel marine engine for ship and boat jinan diesel engine cnpc jichai power 800-1000kw diesel marine engine The Perfect Solution for Your Marine Equipment Requirements
  • 800-1200KW diesel marine engine for ship and boat jinan diesel engine cnpc jichai power 800-1000kw diesel marine engine The Perfect Solution for Your Marine Equipment Requirements
  • 800-1200KW diesel marine engine for ship and boat jinan diesel engine cnpc jichai power 800-1000kw diesel marine engine The Perfect Solution for Your Marine Equipment Requirements
Lugar de origen Porcelana
Nombre de la marca jinan diesel engine
Certificación ce
Número de modelo 12V190
Cantidad de orden mínima 1
Precio 600usd
Detalles de empaquetado Cajas de madera
Tiempo de entrega 30 dias
Capacidad de la fuente 200 piezas mes

Póngase en contacto conmigo para muestras y cupones gratis.

WhatsApp:0086 18588475571

Veloz: 0086 18588475571

Skype: sales10@aixton.com

Si tiene alguna preocupación, ofrecemos ayuda en línea las 24 horas.

x
Datos del producto
Deja un mensaje
Descripción de producto



800-1200KW diesel marine engine for ship and boat jinan diesel engine cnpc jichai power 800-1000kw diesel marine engine The Perfect Solution for Your Marine Equipment Requirements 0

Model Rated Power(kw/hp) Rated speed(r/min) Specific fuel consumption(g/kw’h) Specific oil consumption(g/kw’h) Overall dimension L*B*H(mm) Net weight(kg)
A12V190ZLC 1200/1630 1500 ≤ 205 ≤1.0 2969*1907*2206 9300
A12V190ZLC1 1080/1470 1450 ≤ 205 ≤1.0 2969*1907*2206 9300
A12V190ZLC-1 900/1225 1200 ≤ 205 ≤1.0 2969*1907*2206 9300
A12V190ZLC-2 810/1100 1000 ≤ 205 ≤1.0 2969*1907*2206 9300
L12V190ZLC-1 1200/1630 1200 ≤ 202 ≤1.0 2950*1980*2312 9300
L12V190ZLC-2 1000/1360 1000 ≤ 202 ≤1.0 2969*1980*2312 9300
Main technical data
No. and arrangement of cylinders:12,60.Vee
Type:Four stroke,water cooled,turbocharged and aftercooled,direct injection
Bore:190mm
Stroke:215/255mm
Total displacement:73.15/86.72L
Compression ration:14.5:1
Direction of rotation:Counter-clockwise engine without R,clockwise engine with R in the model(facing to flywheel)
Starting method:Air motor or electric motor
Lubricating method:Pressure and splash lubrication









Main specification of diesel gensets
Model of generating set Model of diesel engines Model of generator Rated Power KW Rated voltage V Rated frequency HZ Overall dimension L*B*H(mm) Net weight KG
CCFJ1000/1500 A12V190ZLCD 1FC6506-4SAA42 1000/1500 390 50 6410*2252*2739 20200
